2022 GEM® e4

2022 GEM® e4

• Motor
• Motor Type48V AC Induction Electric
• Motor Power6.7 HP (5.0 kW)
• Performance
• Top Speed25 mph
• Fuel System
• Fuel SystemVarious
• Range
• Range, CityBattery: 10-90 mile; dependent on battery type
• Drivetrain
• Drive SystemDirect Front Wheel
• SteeringTilt: Optional
• Suspension
• Front SuspensionMacPherson Strut
• Rear SuspensionIndependent Trailing Arm
• Front Travel (in./cm.)5.6 in (14 cm)
• Rear Travel (in./cm.)6 in (15 cm)
• Brakes
• Front braking systemDisc
• Rear braking systemHydraulic Drum
• Parking Brake Hand-Actuated
• Wheels & Tires
• Wheels Stamped Steel, Alum Option
• Front Tire13 in. street-rated 155/80 R13
• Rear Tire13 in. street-rated 155/80 R13
• Hub TypeFront: Aluminum | Rear: Steel
• Dimensions
• Ground Clearance8 in (20 cm)
• Overall Vehicle Size (LxWxH)135 x 55.5 x 73 in (343 x 141 x 185 cm)
• Turning Radius207 in (526 cm)
• Wheelbase101 in (256.5 cm)
• Capacities
• Box Capacity330 lb (150 kg)
• Payload Capacity1,150 lb (522 kg)
• Seating Capacity4
• Towing CapacityHitch: Up to 1100 lb, not to exceed GVWR (off-road use only, max Tongue Weight of 150 lb)
• Weights
• Dry WeightEstimated: 1,350 lb (612 kg)
• GVWR2,500 lb (1,134 kg)
• Lights and Safety
• LightingLED headlights and brake lights, dome light
• Electric
• Electronic Power SteeringOptional
• Features
• FeaturesAdjustable Driver Seat: Standard | Instrumentation: Integrated Backup Camera, Self-cancelling turn signals, 1 kW onboard charger | Other Standard: Bucket seats, safety belts, grab handles, windshield wiper, non-slip flooring, sound emitter | Seat Covering: Charcoal Vinyl
